Maximum Compute Density in 2U
The xFusion FusionServer 2488H V7 packs four 4th Gen Intel Xeon Scalable processors into a 2U chassis – delivering up to 240 cores and 16 TB of DDR5 memory in the same footprint that most servers use for two sockets. It is engineered for memory computing, enterprise databases, HPC, and large-scale virtualization where memory bandwidth and core density directly determine workload throughput.
Key Specifications
| Component | Specification |
|---|---|
| Form Factor | 2U rack server |
| Processor | 2-4x 4th Gen Intel Xeon Scalable (max 350W TDP per CPU) |
| Memory | 64 DDR5 DIMM slots, up to 16 TB |
| Storage | Up to 25x 2.5-inch SAS/SATA/NVMe |
| NVMe | Up to 8 NVMe SSDs |
| PCIe | 9x PCIe 5.0 + 1x OCP 3.0 |
| GPU Support | FHFL GPU accelerators supported |
| Power Supply | 1+1 redundant, 900W/1500W/2000W/3000W |
| Management | iBMC with Redfish API and SNMP |
Ideal Workloads
- In-Memory Databases: SAP HANA, Oracle In-Memory, and Redis clusters that demand low-latency access to terabyte-scale datasets. 16 TB DDR5 across 64 DIMMs eliminates the memory ceiling that constrains 2-socket servers.
- High-Performance Computing (HPC): Computational fluid dynamics, molecular modeling, and financial risk analysis that scale with core count and memory bandwidth. The 4-socket topology provides uniform memory access across all cores.
- Server Consolidation: Replace racks of aging 2-socket servers with a few 2488H V7 nodes. Fewer physical servers means lower power, cooling, and management overhead.
- Virtualization Platforms: VMware vSphere and KVM environments where memory is the first resource constraint. The 2488H V7 supports the VM density that typical 2-socket servers cannot reach.
xFusion Advantage
The 2488H V7 features xFusion intelligent O&M with predictive failure analysis, energy-efficient thermal design supporting 350W CPUs in standard air cooling, and end-to-end security from silicon root of trust through encrypted firmware. Built for 24/7 enterprise operation with hot-swappable drives, power supplies, and fans.
Why Source Through Xincuan?
We configure 2488H V7 servers with competitive pricing, the applicable manufacturer warranty on new units (typically 3 years) and a 12-month warranty provided by us on refurbished units, global logistics with full insurance, and free architecture consultation. Our engineers can model your workload against 2-socket vs 4-socket TCO to validate the right configuration.
Request a 2488H V7 configuration and quote
Related models
Frequently asked questions
Can the configuration be changed before shipping?
Yes. CPU, memory, drives, RAID card, power supply and rails can all be configured to your requirement. Send the target specification and we quote against it.
Are the servers tested before dispatch?
Every unit is powered on, firmware-checked and burn-in tested before dispatch. Test logs or photos can be shared on request.
Do you supply rails, bezel and cable management arm?
Rails and accessories are quoted separately or bundled. Tell us the rack depth and we confirm the right rail kit for the chassis.
Can you confirm the exact model, part number and condition before I order?
Yes. Before the order we send the exact model, part number, condition and full configuration list — CPU, memory, drives, RAID card, power supply — for your written confirmation.
How are warranty and lead time handled?
Warranty and lead time are quoted per order, because they depend on configuration and destination. Condition grade is stated per unit, on every quote line. Nothing is assumed on our side.
