xFusion FusionServer 2288H V7 – 2U Dual-Socket Server for SDS, VDI and CDN

The Versatile 2U Platform for Software-Defined EverythingThe xFusion FusionServer 2288H V7 is the most configurable server in the xFusion lineup - a 2U dual-socket platform supporting up to 2x 4th/5th Gen Intel Xeon Scalable processors at 385W TDP, 32 DDR5 DIMMs (8 TB), 25x 2.5-inch bays with 28 NVMe support, and 14 PCIe 5.0 slots. It is the go-to choice for software-defined storage, virtual desktop infrastructure, content delivery networks, and database clusters where storage density and I/O throughput define performance.Key SpecificationsComponentSpecificationForm Factor2U rack serverProcessor1-2x 4th/5th Gen Intel Xeon Scalable (max 385W TDP)Memory32 DDR5 DIMMs, up to 8 TBStorageFront: Up to 25x 2.5-inch / 20x 3.5-inch SAS/SATA/NVMeNVMeUp to 28 NVMe SSDsPCIe14x PCIe 5.0 + 2x OCP 3.0 mezzanineGPU SupportUp to 4x…

  • Product Details

The Versatile 2U Platform for Software-Defined Everything

The xFusion FusionServer 2288H V7 is the most configurable server in the xFusion lineup – a 2U dual-socket platform supporting up to 2x 4th/5th Gen Intel Xeon Scalable processors at 385W TDP, 32 DDR5 DIMMs (8 TB), 25x 2.5-inch bays with 28 NVMe support, and 14 PCIe 5.0 slots. It is the go-to choice for software-defined storage, virtual desktop infrastructure, content delivery networks, and database clusters where storage density and I/O throughput define performance.

Key Specifications

Component Specification
Form Factor 2U rack server
Processor 1-2x 4th/5th Gen Intel Xeon Scalable (max 385W TDP)
Memory 32 DDR5 DIMMs, up to 8 TB
Storage Front: Up to 25x 2.5-inch / 20x 3.5-inch SAS/SATA/NVMe
NVMe Up to 28 NVMe SSDs
PCIe 14x PCIe 5.0 + 2x OCP 3.0 mezzanine
GPU Support Up to 4x double-wide or 14x single-wide GPUs
Power Supply 1+1 redundant, 900W/1500W/2000W/3000W
Management iBMC with Redfish, SNMP, predictive failure analysis

Recommended Configurations

Scenario CPU Memory Storage GPU
Ceph OSD Node 2x Xeon Gold 6430 (32C) 512GB (16x 32GB) 25x 7.68TB NVMe None
VDI Host (300 seats) 2x Xeon Platinum 8470 (52C) 2TB (32x 64GB) 8x 3.84TB NVMe (RAID 10) 4x NVIDIA A2
CDN Edge Node 2x Xeon Gold 6448Y (32C) 1TB (16x 64GB) 12x 7.68TB NVMe None
Database Cluster 2x Xeon Platinum 8450 (28C) 1TB (16x 64GB) 8x 3.84TB NVMe (RAID 10) None

Ideal Workloads

  • Software-Defined Storage: Ceph, VMware vSAN, and MinIO clusters benefit from the 2288H V7’s 28 NVMe bays – more drives per node means fewer nodes per usable terabyte. 14 PCIe 5.0 slots provide the network bandwidth to keep 28 NVMe drives fed.
  • VDI: Support up to 300 concurrent virtual desktops with GPU acceleration for knowledge workers, designers, and engineers. The 14 PCIe slots enable both GPU risers and high-speed NICs without slot contention.
  • CDN and Streaming: High-density NVMe storage per node reduces edge POP footprint. Dual OCP 3.0 slots keep networking separate from PCIe expansion.
  • Database Clusters: 25 drive bays provide headroom for data growth without adding nodes. Balance SAS HDD bulk storage with NVMe caching tiers in the same chassis.

2288H V7 vs Dell R760: Which 2U Platform?

Feature xFusion 2288H V7 Dell PowerEdge R760
CPU max TDP 385W per socket 350W per socket
NVMe max 28 drives 24 drives
PCIe slots 14x Gen5 + 2x OCP 8x Gen4/Gen5
GPU 4x DW / 14x SW 2x DW / 6x SW
Management iBMC iDRAC9
Best for I/O-heavy SDS, VDI, CDN Balanced enterprise workloads

Why Source Through Xincuan?

We configure 2288H V7 servers for your exact workload with competitive pricing, the applicable manufacturer warranty on new units (typically 3 years) and a 12-month warranty provided by us on refurbished units, global shipping, and free architecture consultation.

Request a 2288H V7 quote

Related models

Frequently asked questions

Can the configuration be changed before shipping?

Yes. CPU, memory, drives, RAID card, power supply and rails can all be configured to your requirement. Send the target specification and we quote against it.

Are the servers tested before dispatch?

Every unit is powered on, firmware-checked and burn-in tested before dispatch. Test logs or photos can be shared on request.

Do you supply rails, bezel and cable management arm?

Rails and accessories are quoted separately or bundled. Tell us the rack depth and we confirm the right rail kit for the chassis.

Can you confirm the exact model, part number and condition before I order?

Yes. Before the order we send the exact model, part number, condition and full configuration list — CPU, memory, drives, RAID card, power supply — for your written confirmation.

How are warranty and lead time handled?

Warranty and lead time are quoted per order, because they depend on configuration and destination. Condition grade is stated per unit, on every quote line. Nothing is assumed on our side.
