SK hynix 32GB DDR5-4800 | ECC RDIMM Server Memory

The 32GB DIMM Is the Most Cost-Effective Way to Populate 16 Memory Channels. Here Is Why.Buy 16x 32 GB DDR5 DIMMs for a dual-socket server and you get 512 GB across all 16 memory channels at 1DPC — full speed, no 2DPC penalty, every channel active. The total cost: roughly $4,000. Buy 16x 64 GB DIMMs for 1 TB instead, and the cost jumps to roughly $8,000 — double the money for double the capacity, but the same number of channels and the same 1DPC speed. The SK hynix 32 GB DDR5-4800 ECC RDIMM is the DIMM you order when you need full channel population, full memory bandwidth, and enough capacity for the workload — without overpaying for capacity you…

  • Product Details

The 32GB DIMM Is the Most Cost-Effective Way to Populate 16 Memory Channels. Here Is Why.

Buy 16x 32 GB DDR5 DIMMs for a dual-socket server and you get 512 GB across all 16 memory channels at 1DPC — full speed, no 2DPC penalty, every channel active. The total cost: roughly $4,000. Buy 16x 64 GB DIMMs for 1 TB instead, and the cost jumps to roughly $8,000 — double the money for double the capacity, but the same number of channels and the same 1DPC speed. The SK hynix 32 GB DDR5-4800 ECC RDIMM is the DIMM you order when you need full channel population, full memory bandwidth, and enough capacity for the workload — without overpaying for capacity you will not use.

Technical Specifications

Parameter Specification
Capacity 32 GB per DIMM
Type DDR5 SDRAM, Registered (RDIMM), ECC
Speed 4800 MT/s (PC5-38400)
CAS Latency CL40 (CL40-39-39 at 4800 MT/s)
Organization 1Rx8 (single-rank, x8 DRAM devices) or 2Rx8 (dual-rank, depending on SKU)
Voltage 1.1V VDD, 1.8V VPP
DRAM Process SK hynix 1a-class (14nm) DDR5 DRAM
On-Die ECC Yes (DDR5 standard — per-subchannel error correction)
Sideband ECC Yes (standard ECC across data bus)
Temperature Sensor Integrated SPD thermal sensor (I2C, read by iDRAC/iBMC)
PMIC On-DIMM Power Management IC (DDR5 standard)
Form Factor 288-pin DDR5 RDIMM, standard height (31.25 mm)
Physical 133.35 x 31.25 mm, ~16g
Temperature 0C to 85C
Qualified Platforms (Dell) PowerEdge R660, R760, R770, R860, R960 (4th Gen Xeon platform)
Qualified Platforms (xFusion) FusionServer 2288H V7, 2488H V7, 5288 V7, 5885H V7
Warranty 3-year (with server)

32 GB vs 64 GB vs 128 GB — The DIMM Density Decision

Scenario Recommended DIMM Size Population Total Capacity Estimated Cost
General virtualization, 16 VMs, moderate density 32 GB 16x (1DPC, all channels) 512 GB ~$4,000
Database server, 1 TB working set 64 GB 16x (1DPC, all channels) 1 TB ~$8,000
VMware host, 100+ VMs, 2 TB needed 128 GB 16x (1DPC) or 32x 64 GB (2DPC, speed penalty) 2 TB ~$16,000
In-memory database, 4 TB needed 256 GB (3DS RDIMM) 16x (1DPC, 16 channels) 4 TB ~$40,000

The 1DPC Speed Rule for 32 GB DIMMs

One DIMM per channel at 4800 MT/s delivers full rated speed. Two DIMMs per channel drop to 4400 MT/s (3DS RDIMM) or 4800 MT/s (standard RDIMM, platform-dependent). For a dual-socket server with 16 memory channels, ordering 16x 32 GB at 1DPC gives you full bandwidth on all 16 channels. Ordering 32x 32 GB forces 2DPC on all 16 channels — no speed penalty on standard RDIMMs at this density, but you lose the option to expand later. Leave half the slots empty if your workload fits in 512 GB; populate all 32 slots only if you need 1 TB.

Compatible Platforms

DDR5-4800 ECC RDIMM. Compatible with Dell PowerEdge R660, R760, R770, R860, R960 (4th Gen Xeon). Also compatible with xFusion FusionServer V7. Verify platform QVL before ordering. Mixing SK hynix with Samsung or Micron DIMMs on the same channel forces both to train down to the slowest common timing — order matched kits.

Source Through Xincuan

We supply SK hynix DDR5 RDIMMs pre-installed in Dell and xFusion servers. competitive pricing, 3-year warranty on new units and a 12-month warranty on refurbished units, and global shipping.

Request a memory-optimized server quote

Related models

Frequently asked questions

Is it ECC RDIMM or unbuffered?

Listed specification: ECC RDIMM Server Memory. We confirm rank, organisation and registered type in writing before the order, because a wrong rank will not post on some platforms.

Which platforms and slot rules apply?

Send the server model and the current memory population. We check the platform memory guide and confirm which slots and mixing rules apply.

Can you supply matched kits?

Yes. Kits are built from the same part number and speed, so channels stay balanced across sockets.

Can you confirm rank, part number and condition before I order?

Yes. Before the order we send rank, speed, part number and condition for your written confirmation.

How are warranty and lead time handled?

Warranty for this part and the lead time are stated on the quotation. For array or cluster builds we align the warranty across all line items.
