New Product Dell EMC PowerVault ME4 ME5 Series ME5012 ME5024 ME5084 ME5212 ME5224 ME5284 Hard Driver Network Storage Server - Sell Dell/Xfusion/Huawei server,From China.

E-mail: admin@sell-server.com



STORAGE/



New Product Dell EMC PowerVault ME4 ME5 Series ME5012 ME5024 ME5084 ME5212 ME5224 ME5284 Hard Driver Network Storage Server

Management support  PowerVault Manager HTML5 GUI element manager, CLI, OpenManage Enterprise VMware vCente  VMware vCenter plugin to manage ME5 arrays through vCenter. Scripting  CLI API Redfish/Swordfish REST API Supported host OS Windows 2025 (including Hyper-V), Windows 2022 (including Hyper-V) RHEL 9.5, 8.10 SLES 15 SLES 15 SP6, SLES 12 SP 8 VMware 9.0, VMware 8.0 U3 Virtualization integration VMware vSphere (ESXi) vCenter; SRM Microsoft Hyper-V Rack size ME5212 (2U), ME5224 (2U), ME5284 (5U) Base system height ME5212: 8.79 cm (3.46 inches)  ME5224: 8.79 cm (3.46 inches)  ME5284: 22.23 cm (8.75 inches) Base system width ME5212: 48.30 cm (19.01 inches)  ME5224: 48.30 cm (19.01 inches)  ME5284: 48.30 cm (19.01 inches) Base system depth ME5212: 61.87mm (24.36 inches)  ME5224: 54.78mm (21.56 inches) …

  • Product Details
Management support
 PowerVault Manager HTML5 GUI element manager, CLI, OpenManage Enterprise
VMware vCente
 VMware vCenter plugin to manage ME5 arrays through vCenter.
Scripting
 CLI API Redfish/Swordfish REST API
Supported host OS
Windows 2025 (including Hyper-V), Windows 2022 (including Hyper-V) RHEL 9.5, 8.10 SLES 15 SLES 15 SP6, SLES 12 SP 8 VMware 9.0,
VMware 8.0 U3
Virtualization integration
VMware vSphere (ESXi) vCenter; SRM Microsoft Hyper-V
Rack size
ME5212 (2U), ME5224 (2U), ME5284 (5U)
Base system height
ME5212: 8.79 cm (3.46 inches)

ME5224: 8.79 cm (3.46 inches)
ME5284: 22.23 cm (8.75 inches)
Base system width
ME5212: 48.30 cm (19.01 inches)

ME5224: 48.30 cm (19.01 inches)
ME5284: 48.30 cm (19.01 inches)
Base system depth
ME5212: 61.87mm (24.36 inches)

ME5224: 54.78mm (21.56 inches)
ME5284: 981mm (38.62 inches)
Weight (max configuration)
ME5212: 32.00 kg (71.00 lbs)

ME5224: 30.00 kg (66.00 lbs)
ME5284: 135.00 kg (298.00 lbs)
Weight (empty)
ME5212: 4.80 kg (10.56 lbs) without drives

ME5224: 4.80 kg (10.56 lbs) without drives
ME5284: 64.00 kg (141.00 lbs) without drives
Rack size
ME512 (2U), ME524 (2U), ME584 (5U)
Expansion height
ME512: 8.79 cm (3.46 inches)

ME524: 8.79 cm (3.46 inches)
ME584: 22.23 cm (8.75 inches)
Expansion width
ME512: 48.30 cm (19.01 inches)

ME524: 48.30 cm (19.01 inches)
ME584: 48.30 cm (19.01 inches)
Expansion depth
ME512: 60.29 cm (23.74 inches)

ME524: 60.29 cm (23.74 inches)
ME584: 97.47 cm (38.31 inches)
Weight

(max configuration)
ME512: 28.00 kg (62.00 lbs)

ME524: 25.00 kg (55.00 lbs)
ME584: 130.00 kg (287.00 lbs)
Weight (empty)
ME512: 4.80 kg (10.56 lbs) without drives

ME524: 4.80 kg (10.56 lbs) without drives
ME584: 64.00 kg (141.00 lbs) without drives
Power/wattage
ME5212: 580W, 764W DC

ME5224: 580W, 764W DC
ME5284: 2200W
Heat dissipation
ME5212: 1980 BTU

ME5224: 1980 BTU
ME5284: 7507 BTU
Voltage
ME512: 100-240 VAC

ME524: 100-240 VAC
ME584: 200-240 VAC
Frequency
50/60 Hz
Amperage
ME512: 7.6-3.0A (x2)

ME524: 7.6-3.0A (x2)
ME584: 11.07-9.23A(x2)
Operating temperature
 5°C – 35°C (41°F – 95°F, derated by 1°C per 300mm above 900m)
Non-operating temperature
-40°C to 70°C (-40 to 158°F) Maximum temperature changes in an hour: 20°C
Operating humidity ranges (non-condensing)
-12C dew point minimum, 8% to 85% maximum, non-condensing
Non-operating humidity (non- condensing)
21°C dew point maximum, 5% to 100% maximum, non-condensing
New Product Dell EMC PowerVault ME4 ME5 Series ME5012 ME5024 ME5084 ME5212 ME5224 ME5284 Hard Driver Network Storage Server - STORAGE - 1
PowerVault ME5200 Series.
The Dell PowerVault ME5 storage platforms are purpose-built for small to medium-sized businesses (SMBs) that value simplicity, affordability, and efficiency. Designed to tackle a wide range of physical and virtual workloads, the ME5 series provides a straightforward, cost-effective way to meet your business’s growing data demands. Ideal for SMBs looking to consolidate block storage or manage data growth without expensive, low-latency flash or NVMe, the PowerVault ME5 offers intelligent data management and scalability. Its architecture supports up to 8PB of capacity, enabling you to expand as your needs evolve—all while keeping operations smooth and reliable. Flexibility is at the core of the PowerVault ME5. With support for multiple protocols and a variety of drive types and capacities, it adapts to your specific requirements. Seamless integration with Dell PowerEdge Servers ensures a cohesive, stress-free experience. Plus, the all-inclusive software delivers the tools you need to store, organize, and protect your critical data in one easy-to-use package. For SMBs seeking a storage solution that’s both affordable and simple to
manage, the Dell PowerVault ME5 strikes the perfect balance. It’s a scalable, flexible, and future-ready platform designed to help your business thrive in a data-driven world. Using fast Intel Xeon processors, Dell PowerVault ME5 storage implements a dual-active controller architecture, 12GB/sec read, and 10GB/sec write throughput and uses a 12Gb SAS backend protocol for rapid capacity expansion.
