Low-Price Dell EMC PowerEdge R650 R650xs 1U Rack Server with Intel Xeon Silver/Gold/Platinum/CPU/64G RAM/750W Power

Model	D ELL R650
Appearance Specifications	1U
processor	Supports up to two 3rd generation Intel Xeon Scalable processors (up to 40 cores per processor)
Processor interconnection	Intel Hyperpath Interconnect (UPI)
Memory	32 DDR4 DIMM slots, supporting maximum RDIMM 2 TB or LRDIMM 4 TB, with speeds up to 3200 MT/s Up to 8 NVDIMM slots, up to a maximum of 128 GB Up to 16 Intel Permanent Memory 200 Series (BPS) slots, with a maximum capacity of 8 TB Only supports registered ECC DDR4 DIMMs
Storage Drive	Internal controllers: PERC H745, HBA355I, A50, H345, H755, H755N • Boot optimized storage subsystem (BOSS-S2): HW RAID 2 x M.2 SSD 240 GB or 480 GB External PERC (RAID): PERC H840, HBA355E
PCIe slot	Up to 3 PCIe 4.0 half height slots (all x16 except for one x8 slot with SNAPI I/O option) or 2 PCIe (4.0) full height slots
USB port	Front port: •1 dedicated iDRAC Direct micro USB • 1 USB 2.0 • 1 VGA Rear port: ●1 USB 2.0 ● 1 serial (optional) ● 1 USB 3.0 ● 2 x Ethernet ● 1 VGA internal port: ● 1 USB 3.0 (optional)
GPU	Up to three 75W single width GPUs
Power	• 800 W AC/240 HVDC • 1100 W AC/240 HVDC • 1400 W AC/240 HVDC
System management	Encryption signature firmware • Safety guidance • Secure erasure • Silicon wafer trust root System lockout (requires iDRAC9 Enterprise or Datacenter) TPM 1.2/2.0 FIPS, CC-TCG certification, TCM 2.0 (optional)
Networking options	1 x OCP 3.0 (x8 PCIe channel)
