Stock Lenovos 10Gb iSCS/16Gb FC Universal SFP Module 10Gbs Fiber Optic Communication Module Transceivers Networks

Avago Technologies’ AFBR-57F5UMZ optical transceiver
supports high speed serial links over multi-mode opti
cal fiber at signalling rates up to 14.025Gb/s (the serial
line rate of 16GFC). The product is compliant with Small
Form Pluggable industry agreements SFP and SFP+ for
mechanical and low speed electrical specifications. High
speed electrical and optical specifications are compliant
with ANSI Fibre Channel FC-PI-5.
Características
• Compliant to RoHS directives
• 850nm Vertical Cavity Surface Emitting Laser (VCSEL)
• Class 1 eye safe per IEC60825-1 and CDRH
• Wide temperature range (0°C to 70°C)
• LC duplex connector optical interface conforming to
ANSI TIA/EIA604-10 (FOCIS 10A)
• Diagnostic features per SFF-8472 “Diagnostic
Monitoring Interface for Optical Transceivers”
The AFBR-57F5UMZ is a multi-rate 850nm transceiver
which ensures compliance with FC-PI-5 16GFC, 8GFC and
4GFC specifications. The transceiver also supports 16GFC
and 10G Ethernet (10GE) traffics, both up to 100m using
OM3 multimode fiber (FMM) and 125m using OM4 MMF.
Per the requirements of 16GFC, internal clock and data
recovery circuits (CDRs) are present on both electrical in
put and electrical output of this transceiver. These CDRs
will lock at 14.025Gb/s (16GFC) but must be bypassed
for operation at 10.3125Gb/s (10GE), 8.5Gb/s (8GFC), e
4.25Gb/s (4GFC), accomplished by using two Rate Select
inputs to configure transmit and receive sides. Transmitter
and receiver can operate at different data rates, as is often
seen during Fibre Channel speed negotiation.
Digital diagnostic monitoring information (DMI) is present
in the AFBR-57F5UMZ per the requirements of SFF-8472,
providing real time monitoring information of transceiver
laser, receiver and environment conditions over a SFF
8431 2-wire serial interface.
produtos relacionados
• AFBR-57D7APZ: 850nm SFP for 8G/4G/2G Fibre Channel
• AFCT-57D5ATPZ: 1310nm SFP for 8G/4G/2G Fibre Channel
• AFCT-57D5ANPZ: 1310nm SFP for 8G/4G/2G Fibre
Channel
• AFBR-57R5APZ: 850nm SFP for 4G/2G/1G Fibre Channel
• AFCT-57R5APZ: 1310nm SFP for 4G/2G/1G Fibre Channel
• AFCT-57R5ATPZ: 1310nm SFP for 4G/2G/1G Fibre Channel
• AFCT-57R5ANPZ: 1310nm SFP for 4G/2G/1G Fibre Channel
• Enhanced operational features including EWRAP,
OWRAP and variable electrical EQ/emphasis settings
• Real time monitoring of:- Transmitter average optical power- Received average optical power- Laser bias current- Temperature- Supply Voltage
• SFP+ mechanical specifications per SFF-8432
• SFP+ compliant low speed interface
• Fibre Channel FC-PI-5 compliant high speed interface- 1600-SN-M6-S, 800-SN-M6-S, 400-SN-M6-I- 1600-SN-M5-S, 800-SN-M5-S, 400-SN-M5-I- 1600-SN-M5E-I, 800-SN-M5E-I, 400-SN-M5E-I- 1600-SN-M5F-I, 800-SN-M5F-I, 400-SN-M5F-I
• Fibre Channel FC-PI-5 compliant optical link distances
• Interoperable with 10GE compliant transceivers
@10.3125Gb/s per IEEE 802.3ae 10GBASE-SR standard
and Avago’s 10G-USR transceivers up to 100m using
OM3 MMF and 125m OM4 MMF
Applications
• Fibre Channel switches (director, stand alone, blade)
• Fibre Channel Host Bus Adapters and 16GFC/10GE
Converged Network Adapters
• Fibre Channel RAID controllers
• Fibre Channel tape drive
• Port side connections
AFBR-57F5UMZ
• Inter-switch or inter-chassis aggregated links
