Dell 5T78C / KPM6WRUG7T68 7.68TB 2.5 SFF 24Gbps Read Intensive 1-DWPD BICS Flash TLC SAS SED / FIPS 140-2 Encrypted SSD – Nuovo di zecca
PM6-R Series SSDs – Enterprise Read Intensive
PM6-R Series 24G SAS Enterprise SSD is optimized for read intensive applications, compresi i servizi web, archiviazione dei dati, streaming media and video on demand. The series provides high levels of performance, affidabilità e resistenza, ed è progettato per ridurre al minimo il costo totale di proprietà.
Featuring Corporation’s 96-layer BiCS FLASH 3D flash menory, this 6th generation enterprise SAS SSD PM6-R Series offeres 1-DWPC (Dreive Writes Per Day)
KEY Features
- 24G SAS interface with single/dual-port support
- Capacities from 960GB to 30.72 tubercolosi
- Supporto di scrittura multi-flusso T10
- Up to 595K random read IOPS (4 KiB) in dual-port mode
- 2.5 form factory 15mm height
- 1 DWPD con 100% Carico di lavoro di scrittura casuale
- Power-Loss-Protection and End-to-End Data Protection, Including T10 DIF
- Pin-3 Power Disable Support
- Disinfetta la cancellazione istantanea (LEI) opzione
- Self Encrypting (Sed & SED FIPS 140-2) options
DPN: 5T78C
MPN: SDFUS73DHB02T
KIO-KPM6WRUG7T68-BN-OE-DEL
Alternate Part Numbers: 5T78C 05T78C SDFUS73DHB02T
| Enterprise Read Intensive SSD | |
|---|---|
| Basic Specifications | |
| Reliability | |
| Power Requirements | |
| Dimensioni | |
| Enviromental | |
| Model Number | KPM6WRUG7T68 |
| Interfaccia | SAS-4.0 |
| Interface Speed | 22.5 Gbit/sec ,12.0 Gbit/sec , 6.0 Gbit/sec , 3.0 Gbit/sec , 1.5 Gbit/sec |
| Tipo di memoria | BiCS FLASH TLC |
| Formatted Capacity | 7.68tubercolosi |
| Sustained 128 KiB Sequential Read | 4,150 MiB/s |
| Sustained 128 KiB Sequential Write | 3,750 MiB/s |
| Sustained 4KiB Random Read | 595,000 IOPS |
| Sustained 4KiB Random Write | 115,000 IOPS |
| MTTF | 2,500,000 ore |
| DWPD | 1 |
| Supply Voltage | 5 V ±7 % , 12 V ±7 % |
| Power Consumption (Operativo) | 5.0W Typ. |
| Altezza | 15.0 mm +0 , -0.5 mm |
| Larghezza | 69.85 ±0.25 mm |
| Length | 100.45 mm Max. |
| Peso | 130 g Max. |
| Temperature (Operativo) | 0 A 70 °C |
| Relative Humidity ( Operativo ) | 5 A 95 % R.H. |
| Vibration (Operativo) | 21.27 m/s {2.17 Grms} (5 A 800 Hz) |
| Shock (Operativo) | 9.8 km/s {1,000 G} (0.5 msec) |
Dell 5T78C / Kioxia KPM6WRUG7T68 7.68TB SFF 24Gbps Read Intensive 1-DWPD BICS Flash TLC SAS SED / FIPS 140-2 Encrypted SSD – Nuovo di zecca
Dell 5T78C / Kioxia KPM6WRUG7T68 7.68TB 2.5″ SFF 24Gbps Read Intensive 1-DWPD BICS Flash TLC SAS SED / FIPS 140-2 Encrypted SSD – Nuovo di zecca
PM6-R Series SSDs – Enterprise Read Intensive
PM6-R Series 24G SAS Enterprise SSD is optimized for read intensive applications, compresi i servizi web, archiviazione dei dati, streaming media and video on demand. The series provides high levels of performance, affidabilità e resistenza, ed è progettato per ridurre al minimo il costo totale di proprietà.
Featuring KIOXIA Corporation’s 96-layer BiCS FLASH 3D flash menory, this 6th generation enterprise SAS SSD PM6-R Series offeres 1-DWPC (Dreive Writes Per Day)
KEY Features
- 24G SAS interface with single/dual-port support
- Capacities from 960GB to 30.72 tubercolosi
- Supporto di scrittura multi-flusso T10
- Up to 595K random read IOPS (4 KiB) in dual-port mode
- 2.5″ form factory 15mm height
- 1 DWPD con 100% Carico di lavoro di scrittura casuale
- Power-Loss-Protection and End-to-End Data Protection, Including T10 DIF
- Pin-3 Power Disable Support
- Disinfetta la cancellazione istantanea (LEI) opzione
- Self Encrypting (Sed & SED FIPS 140-2) options
DPN: 5T78C
MPN: SDFUS73DHB02T
